GPU
5nm GPU
AMD RDNA™ 3 Architecture
Engine Clock
- Boost Clock: Up to 2560 MHz
- Game Clock: Up to 2220MHz
Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads.
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
Stream Processors
Compute Units
Infinity Cache
Ray Accelerators
Memory Size/Bus
Memory Clock
Displays
Resolution
- HDMI™: 7680×4320
- DisplayPort 2.1: 7680×4320
Interface
PCI-Express 4.0 x16
Output
- 2x HDMI
- 2x DisplayPort
BIOS Support
- Dual UEFI
Game Index
4K
Sapphire Features
- Dual BIOS
- TriXX Software Switch
- Premium Digital Power Design
- Ultra High Performance Conductive Polymer Aluminum Capacitors
- Fuse Protection
- Tri-X Cooling Technology
- Vapor-X Cooling
- High TG Copper PCB
- Optimized Composite Heatpipe
- Intelligent Fan Control
- Precision Fan Control
- Metal Backplate with ARGB
- Dual ARGB Light Bar
- Two-Ball Bearing Fans
- Angular Velocity Fan Blade
- Assistive System Fan Control
- Die Casted Aluminum-Magnesium Alloy Frame
- Frontplate Heatsink for VRM
- Wave Fin Design
- V Shape Fin Design for GPU Cooling
- TriXX Supported
- Fan Check
- Fan Quick Connect
- TriXX Boost
- NITRO Glow
- External RGB LED MB Synchronization
Accessories Bundled
- Graphics Card Supporter
- ARGB Extension Cable
AMD Features
- AMD RDNA™ 3 Gaming Architecture
- 84 AMD RDNA™ 3 Compute Units (with RT+AI Accelerators)
- 80MB AMD Infinity Cache™ technology
- DisplayPort™ 2.1
- AMD Radiance Display™ Engine
- AMD Radeon™ Boost technology*
- AMD Radeon™ Anti-Lag* technology*
- 20GB GDDR6 on 320-Bit Memory Bus
- PCI® Express 4.0 ready
- AMD FidelityFX™ technologies*
- AMD FidelityFX™ Super Resolution technology*
- Microsoft® DirectX® 12 Ultimate
- Microsoft® DirectStorage
- Vulkan® Optimized
- AMD smart technologies*
- AMD Software: Adrenalin Edition™ application
- AMD Noise Suppression*
- AMD Privacy View*
- AMD Radeon™ Super Resolution technology*
- AMD Link*
- AMD Freesync™ technology
Cooling
3 Fans
Vapor-X Cooling
Form Factor
Dimension: 320(L)X 135.75(W)X 71.6 (H)mm
Power Consumption
368W Total Board Power
OS
Linux®, Windows® 10, and Windows 11. 64-bit operating system required
System Requirement
- Minimum 750 Watt Power Supply
- 3 x 8-pin Power Connector.
- PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
- Minimum 8GB of system memory. 16GB recommended.
